myMix – BASIC UNIT

BUY NOW

The myMix personal monitor mixer is the main building block for any myMix system. It can be used stand alone, or connected to an Ethernet switch as a system with up to 250 devices.

The user can select from all available audio channels in the network and create an individual stereo mix for headphones, in-ear monitors and (powered) speakers.

Each myMix can create a stereo mix using the internal stereo FX, tone control and panning selecting up to 16 from up to 500 network channels and put this signal to headphones or in/ears, drive power speakers or transmitters for wireless IEMs. This stereo mix can be also be sent back to the network, for others to listen to a mix, or use it as submix within myMix.

The local inputs are for microphone (XLR) or line level (1/4″ TRS) sources; phantom power is available. The channels to select for the mix can be from an IEX16 input expander, other local myMix inputs , other stereo mixes, or the tracks from SD cards in Playback mode.

With a single press of the RECORD button the selected audio channels get recorded in multi-track as 24-bit, 48kHz broadcast wav files. These files can be used with any DAW software or played back and remixed (virtual sound check). In Play Along Mode the two local inputs can be mix with the recorded tracks- a powerful tool to turn a practice at home into a full band rehearsal.

Features

  • Impeccable audio quality with 24-bit, 48 kHz throughout the system
  • Create a stereo mix using up to 16 from 500* audio channels
  • Intuitive User Interface with meaningful channel names
  • Volume, Tone Control, Effect Send, Pan, solo and Mute per channel
  • 7 integrated stereo effects to create a 3-D sound image
  • Autosave of all chages applied to the mix, with 20 profiles available.
  • 2 local network inputs (mic/line level) with phantom power
  • Multi-track recording (16 +2) on SD cards (24-bit wav-files)
  • Auto saving in up to 20 profiles
  • 4-band fully parametric master EQ
  • Send Mix to Network to listen to other devices or create submixes
  • Outputs for balanced line levels and headphones
  • Ships with microphone stand adapter and power-supply

For use in recording studios the myMix Studio-Mod with a modified silent cooling system is available.

* A myMix system can feature up to 500 audio channels (250 pairs) maximum.

BUY NOW

Similar myMix Products

MIX PACK 4

MIX PACK 4

A starter package with everything needed to provide individual mixes and multi-track recording for 4 or even 7 musicians. All devices get connected with a network cable to the POE switch.

read more
MIX PACK 5

MIX PACK 5

A starter package with everything needed to provide individual stereo mixes and multi-track recording for 4 vocalists and 7 musicians with 26 audio channels to select from.

read more

MIX PACK 4

MIX PACK 4

by | Nov 20, 2019 | Mixpacks

All-YOU-NEED starter set.

PERFECT FOR 4 MUSICIANS.

BUY NOW
4x

BASIC 8 Network
Switch

T the MIXPACK 4 starter package contains everything needed to provide individual stereo mixes and multi-track recording for four or more musicians.

Four myMix units provide eight inputs to connect and label microphone (phantom power available) and line level sources. All devices get connected with a CAT5* cable to the included POE switch. If you want to share the input signals with a console you can split the signal from DI-boxes for line level and use y-cable (or a mic split box) for microphones.

If you have more than four people on stage, consider using a 4-ch headphone amp and share a mix (e.g. for the vocalists). The POE switch provides power for up to 8 myMix units, so you can add 4 more myMix or 3 myMix and an IEX16 input expander to have more individual mixes and more audio channels available.

Should you ever outgrow this system all you need to get is a larger switch with more ports.

The MIXPACK 4 set includes:

  • 4 x myMix unit,
  • 1 x 8-port POE switch (BASIC 8)
  • 8 audio inputs (4 x 2)
  • 4 x Multi-Track Recording and Playback
  • Power supplies

Easy to expand by simply adding more myMix!

*CAT5 and audio input cables are not included in the package.

Applications examples

The examples demonstrate, how the MIXPACK 4 can work for a7 piece band with the help of some accessories.
By adding one more myMix even a 8 piece band gets started with the leading monitoring system.

Similar myMix Products

MIX PACK 4

MIX PACK 4

A starter package with everything needed to provide individual mixes and multi-track recording for 4 or even 7 musicians. All devices get connected with a network cable to the POE switch.

read more
MIX PACK 5

MIX PACK 5

A starter package with everything needed to provide individual stereo mixes and multi-track recording for 4 vocalists and 7 musicians with 26 audio channels to select from.

read more

MIX PACK 5

MIX PACK 5

by | Oct 24, 2019 | Mixpacks

All-YOU-NEED starter set.

PERFECT FOR 5 MUSICIANS.

BUY NOW
5x

IEX16L-A
16x input expander

Network
Switch

T the MIXPACK 5 package contains everything needed to provide individual stereo mixes and multi-track recording for five musicians.

Using up to 10 local inputs from myMix- and 16 from an IEX16L-A input expander there are 26 audio channels to select from. All devices get connected with a CAT5* cable to the Power8 switch. Connect your audio inputs to the IEX16L-A and/or myMix and start.

With the 8-port network switch, you can easily expand the system by adding three more myMix and/or the myMix Control, or a second IEX16L-A input expander. The GB uplink port on the switch allows to connect to a second switch – all by simply plug and play.

The MIXPACK 5 set includes:

  • 5 x myMix unit,
  • 1 x IEX16L-A **
  • 1 x 8-port POE switch
  • 26 audio inputs (16 + 5 x 2)
  • 5 x Multi-Track Recording and Playback in the units
  • Power supplies

Easy to expand by simply adding more myMix!

*CAT5 and audio input cables are not included in the package.
** Also available as Mix Pack 5A with IEX16L without digital inputs in ADAT format.

BUY NOW

Application example

The system example is showing a MixPack5 or 5A being used for 4 vocalists and 7 musicians.

Similar myMix Products

MIX PACK 4

MIX PACK 4

A starter package with everything needed to provide individual mixes and multi-track recording for 4 or even 7 musicians. All devices get connected with a network cable to the POE switch.

read more
MIX PACK 5

MIX PACK 5

A starter package with everything needed to provide individual stereo mixes and multi-track recording for 4 vocalists and 7 musicians with 26 audio channels to select from.

read more

MIX PACK 8

MIX PACK 8

by | Sep 24, 2019 | Mixpacks

All-YOU-NEED starter set.

PERFECT FOR 8 MUSICIANS.

BUY NOW
8x

IEX16L
16x input expander

Network
Switch

T the MIXPACK 8 contains everything needed to provide individual stereo mixes and multi-track recording for eight musicians.

Using up to 16 local inputs from myMix- and 16 from an IEX16L-A input expander, there are 32 audio channels to select from. All devices get connected with a CAT5* cable to the network switch, connect your audio inputs (analog or digital) to the IEX16L-A and/or myMix and start.

The 8-port switch allows you to easily expand the system; one extra port for myMix Control, or an additional IEX16L-A; the GB uplink port allows connection to other switches (e.g. a second switch) – all plug and play.

The MIXPACK 5 set includes:

  • 8 x myMix unit,
  • 1 x IEX16L-A **
  • 10-port POWER 8 switch
  • 32 audio inputs (16 + 8 x 2)
  • 8 x Multi-Track Recording and Playback in the units
  • Power supplies

Easy to expand by simply adding more myMix!

* CAT5 and audio input cables are not included in the package.
** Also available with IEX16L without  digital inputs in ADAT format.

BUY NOW

Application example

8 myMix for musicians on stage. 16 signals are fed from the console (direct outs and aux sends) to the IEX16L (A). This setup allows musicians to create their mixes from an individual selection, while mixes of music and speech are sent to the overflow and cry room.
